Abstract—
Three-level PWM dc–dc converters convert high dc voltage (>500 V) generally at the output of a three-phase ac–dc PWM rectifier in ac–dc converters to an isolated dc output voltage which can be used to power data center loads. Strict efficiency requirements at loads from 20% to 50% of full load of ac–dc converters for telecom applications have been introduced by energy star enforcing industries to improve efficiency of the dc–dc converter in an ac–dc converter powering data-center loads at those loads. High-efficiency requirements at low and mid loads in high switching frequency PWM dc–dc three-level converters implemented with MOSFETs can be achieved by reducing switching losses through optimized load adaptive ZVS for the entire load range. In this paper, a simple yet novel load adaptive ZVS auxiliary circuit for three-level converter is proposed for so that the resulting three-phase ac–dc converter can meet energy star platinum efficiency standard. The operation of the proposed dc–dc converter is described, analyzed, and validated by experimental results from an industrial prototype of a three-phase ac–dc converter comprising of a front-end three-phase boost PWM rectifier followed by the proposed converter.
Three-level PWM dc–dc converters convert high dc voltage (>500 V) generally at the output of a three-phase ac–dc PWM rectifier in ac–dc converters to an isolated dc output voltage which can be used to power data center loads. Strict efficiency requirements at loads from 20% to 50% of full load of ac–dc converters for telecom applications have been introduced by energy star enforcing industries to improve efficiency of the dc–dc converter in an ac–dc converter powering data-center loads at those loads. High-efficiency requirements at low and mid loads in high switching frequency PWM dc–dc three-level converters implemented with MOSFETs can be achieved by reducing switching losses through optimized load adaptive ZVS for the entire load range. In this paper, a simple yet novel load adaptive ZVS auxiliary circuit for three-level converter is proposed for so that the resulting three-phase ac–dc converter can meet energy star platinum efficiency standard. The operation of the proposed dc–dc converter is described, analyzed, and validated by experimental results from an industrial prototype of a three-phase ac–dc converter comprising of a front-end three-phase boost PWM rectifier followed by the proposed converter.
